Tsib Eccentric Ntsej Muag Npauj Npaim Valve
Kev txiav txim siab thiab siv tsis ncaj rau lub rooj sib tw, lub pob hloov tau sib xyaw ua ke npauj npaim phaj ntim lub nplhaib tsim, yuav tsis ua rau lub tshuab tag nrho cov ntawv qhia cov nqi vim muaj teeb meem foob hnav; tag nrho lub tshuab tuaj yeem ua kom tiav thiab rov qab sib sau rau ntawm qhov chaw, uas yog, txhua yam khoom siv tuaj yeem tuaj yeem kho chaw thiab hloov tau tuaj yeem txo tus nqi siv sijhawm ntev ntawm cov khoom.Multi-eccentric tsim ua lub sealing nto tsis tuaj yeem, nthuav dav thermal thiab daim ntawv cog lus yog ntau yam tsis sib thooj, thiab daim ntawv thov ntau dua.
Tsim Nta +
Txhawm rau teb rau cov kev xav tau ntawm kev ua haujlwm sib txawv, peb tau tsim quintuple eccentric hlau rau hlau bi-kev coj npauj npaim valve ntawm lub hauv paus ntawm triple eccentricity.
Plaub-eccentric npauj npaim valve nrog plaub tus qauv eccentric;
Thawj tus yog eccentric; qhov chaw nruab nrab ntawm lub voj voog tseeb yog eccentric, thiab txhua qhov sib txuam ntawm lub nplhaib sib khi sib tshuam mus rau qhov nruab nrab ntawm qhov channel yog lub voj voos tseeb, thiab qhov chaw nruab nrab ntawm txhua lub ntsej muag yog eccentric rau txoj kab nruab nrab ntawm cov channel.
Qhov ob yog eccentric; lub puab tsaig yog eccentric, qhov chaw sib khi tau muab tso rau sab ntawm lub pob valve, thiab qhov chaw sib khi yog eccentric rau lub valve kav,
Qhov thib peb yog eccentric; txoj kab uas hla yog eccentric, lub pob valve yog nyob rau ib sab ntawm qhov chaw nruab nrab ntawm lub pob valve, thiab lub pob valve yog eccentric rau qhov chaw nruab nrab ntawm cov channel.
Plaub eccentric, sab saum toj ntawm elliptical lub khob hliav qab yog eccentric, thiab cov kab sib tshooj ntawm lub nplhaib zoo kawg nkaus lub nplhaib txuas ntxiv tau tsim los ua lub elliptical lub khob hliav qab, thiab sab saum toj ntawm elliptical lub khob hliav yog eccentric mus rau qhov chaw ntawm lub channel.
Thib tsib eccentricity; Quadruple offset bevel seem ntawm ncua lub khob hliav qab, lub voj voog zoo, lub nplhaib sib khi.
Tus Qauv Tsim Qauv +
Tsim: API 609
Ntsej muag ntsej muag: API609 / ISO5752-20 / ISO5752-13 / DIN F4 / EN558
Ange Flange xaus: ASME B16.5 / ASME B16.47 / EN1092-1 / GOST 12815 / Gost 33259 / MSS-SP44
· Taub Qab Vuam Xaus Xeem: ASME B16.25
Kev Xeem: API598
Safe Kev nyab xeeb rau hluav taws: API607 / API6FA
Kev Qhia Tshwj Xeeb +
· Loj: 2 "~ 104" (DN50 ~ DN2600)
· Chav Kawm: 150LB ~ 2500LB / PN6 ~ PN420
Kev Txuas Lus: Muab ob npaug rau flange / Taub Qab weld / Lug / Wafer
Ua Haujlwm: Worm iav / Pneumatic actuator / hluav taws xob actuator
· Qhov kub thiab txias: -196 ~ 900 ℃
· Daim Ntawv Thov: Kev kub ncaj qha / Cov hlau thiab hlau smelting / LNG / Cov nroj tsuag fais fab / hluav taws xob crystalline / hmoov / hmoov hnoos qeev ect ntau yam haujlwm hnyav
Khoom Siv Khoom Xaiv +
· Lub cev& Disc: Carbon hlau (WCB, LCB)
· Cov hlau tsis muaj zog (CF8, CF8M, CF3, CF3M) /
· Duplex stainless hlau (4A, 5A, 6A) /
Ast Hastelloy alloy (N-12MV, CW-12MW, CW-2M) /
Con Inconel alloy (CY-40, CW-6MC) /
· Monel alloy (M35-1) /
· Aluminium bronze alloy (C95400, C95500, C95800, AB2C)
Cov Qauj: SS420 / 17-4PH / F51 / F53 / XM-19 / Monel-K500 / Inconel-625 / Hastelloy-276 / Titanium
Se Disc Sealing: / F304+ Nitriding / F304+STL / F316+ Nitriding / F316+STL
· Lub Rooj Tog Zaum: / F304+ Nitriding / F304+STL / F316+ Nitriding / F316+STL
Cov ntsiab lus hauv +
Mucus nrog cov kua dej.
Cov hmoov txhuam.
Crystallization kua.
Ua kua dej kub txawv qhov ua kua.
Fiber ntau.
Kub siab ua kom muaj zog ntsev.
Bi-kev taw qhia cua sov network npauj npaim valve.
Cryogenic, LNG npauj npaim valve.
Kev kub siab 2500lb npauj npaim valve.
Siab kub 1100 ℃ npauj npaim valve.
Cov ntaub ntawv pov thawj tawg, fireproof thiab antistatic npauj npaim valve.
Tus qauv tshwj xeeb npauj npaim valve rau kev txuag kom sov thiab ua kom huv
